Introduction
● 26 years of EM/IR verification experience
– IR/EM is an analog noise that impacts on
timing (skew margin / how much IR noise will
impact on draw)
● Many experiences of EM/IR closure for tape out
● Many experiences of spice verification of IR/EM
problem nodes
● Consulting of EM/IR analysis is welcomed
● Contact information
- email: jimmy.gong@emir-sim.com
- phone number: (669) 837-0857
Evaluation Procedure
- Create DSPF file including P/G nets and instance sections
- Modify resistance value on P/G nets that you want to validate of IR/EM result easily
- Run fast spice simulation and measure the IR drop value on the P/G nets
- Please contact us for NDA
- Run EMIRSiM and compare the result with your fast spice run result
What’s EMIRSiM?
● Dynamic Transistor Level EM/IR detection tool in fast speed
– Since EM/IR is dynamic noise
● Easy to use
– Not many control commands are necessary
● Easy to evaluate
– Prepare DB to evaluate
— DSPF / SPICE,
Spectre/Spice Run setup
– Sign NDA
-Compare the result
● Please contact jimmy.gong@emir-sim.com
